Specifications
Model : CS-H6c-R105-1L3WF

Camera
Image Sensor :1/2.7″ Progressive Scan CMOS
Shutter Speed: Self-adaptive shutter
Lens: 4mm @ F1.6, viewing angle: 82° (Horizontal), 48° (Vertical), 98° (Diagonal)
Lens Mount: M12
Day & Night: IR-cut filter with auto-switching
DNR: 3D DNR
WDR: Digital WDR

Compression
Video Compression: H.264/H.265
Video Bit Rate: Adaptive bit rate.

Max. Resolution: 2304 × 1296
Frame Rate: Self-Adaptive during network transmission

Network
Smart Alarm: Motion Detection, Human Shape Detection, Loud Noise Detection
Wi-Fi Pairing: AP paring
Protocol: EZVIZ Cloud Proprietary Protocol
Interface Protocol: EZVIZ Cloud Proprietary Protocol

Interface
Storage: Supports microSD card (Up to 512 G)
Power: TYPE-C
Wired Network: RJ45 X 1 (10M/100M self-adaptive Ethernet port)

Wi-Fi
Standard: IEEE802.11b, 802.11g, 802.11n
Frequency Range: 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth: Supports 20MHz
Security: WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate: 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps
Output Power(EIRP): 19 dBm
Antenna Gain: 1.9 dBi

General
Operating Conditions: -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
Power Supply: DC 5V/1A
Power Consumption: 5W max
IR Range: MAX. 10 meters (33ft)
Dimensions: 88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
Packaging Dimensions: 103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
Bare Weight: 218g (0.48lb)

In the box
– Camera
– Power Adapter
– Power Cable
– Drill Template
– Mounting Plate
– EZVIZ Screw Kit
– Regulatory Information
– Quick Start Guide
