Deskripsi

Specifications

Model CS-H8c Pro (2K)



Camera

Image Sensor 1/2.8″ Progressive Scan CMOS

Shutter Speed Self-adaptive shutter

Lens 4mm@ F1.6, viewing angle: 49° (Vertical), 89° (Horizontal), 104° (Diagonal) 6mm@ F1.6, viewing angle: 28° (Vertical), 52° (Horizontal), 60° (Diagonal)

PT Angle Pan: 350°, Tilt: 80°

Minimum Illumination 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)

Lens Mount M12

DNR 3D DNR

WDR Digital WDR

Black & White Night 30m / 98ft



Video & Audio

Max Resolution 2304*1296

Frame Rate Max:30fps; Self-Adaptive during network transmission

Video Compression H.265 / H.264

H.265 Type Main Profile

Video Bit Rate Ultra-HD; Hi-Def; Standard. Adaptive bit rate.

Audio Bit Rate Self-Adaptive



Network

Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n

Frequency Range 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth Supports 20MHz

Security WPA-PSK/WPA2-PSK

Transmission Rate 11b 11 Mbps, 11g 54 Mbps, 11n: 72 Mbps

Wi-Fi Pairing AP paring

Protocol EZVIZ Cloud Proprietary Protocol

Interface Protocol EZVIZ Cloud Proprietary Protocol

Wired Network RJ45 × 1 (10M / 100M Adaptive Ethernet Port)



Functions

Smart Alarm AI-Powered Human Shape Detection

Auto Tracking Supports

Customized Alert Area Supports

Two-way Talk Supports

Preset Locations Supports

General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark



Storage

Local Storage Supports microSD Card (Up to 512 GB)

Cloud Storage Supports EZVIZ CloudPlay storage (Subscription required)

General

Operating Conditions -30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing)

IP Grade Weatherproof Design

Power Supply DC 12V/1A

Power Consumption MAX. 12W

Dimensions 100 × 136 × 140mm (3.94 × 5.35 × 5.51 inch)

Packaging Dimensions 140 × 140 × 192mm (5.51 × 5.51 × 7.56 inch)

Weight Net Weight: 516g; With Package: 820.5g For EU Standard Version



In the box

In the box – H8c Pro 2K Camera

– Drill Template

– Screw Kit

– Waterproof Kit

– Power Adapter

– Regulatory Information

– Quick Start Guide



Certifications

Certifications CE / UL / RoHS / WEEE / REACH
